Automatic Chicken Door Duo Smart

The smart control unit for chicken doors provides reliable protection against nocturnal predators and enables the automatic opening and closing of flaps or sliders on poultry houses depending on daylight or fixed times. Convenient operation via an app.

  • control for fully automatic, daylight and time-dependent opening and closing of chicken doors up to 2.5 kg)
  • convenient operation via the Kerbl app via local WLAN - settings and manual opening and closing can be conveniently controlled directly via the smartphone, relevant messages are also displayed directly in the app
  • safe mechanism that protects the poultry house from nocturnal predators (foxes, martens, etc.)
  • daylight-dependent control: the integrated light sensor in the housing determines the current daylight level and opens and closes the door according to the set brightness value
  • time-dependent control: fixed opening and closing times for consistent daily routines
  • manual control via the app or via connected optional external button (70565) possible
  • user-friendly design enables quick installation and simple operation
  • LED indicator light shows the current status of the automatic chicken door control unit
  • optional external light sensor (70554) with 1 m cable allows indoor installation of the control
  • no unintended opening caused by lightning flashes or short-term brightness, thanks to time-delayed reaction by light sensor
  • increased safety thanks to automatic motor switch-off in the event of overload and stop function if resistance is met with subsequent continuation of the closing mechanism
  • adjustable weekend mode: individual door opening times can be freely selected at the weekend
  • Mains operation required, solar battery set (70556) for self-sufficient power supply available separately
Items
Ref. no.DescriptionWidthHeightDiameterColourSizePU
70521Control unit7.5 cm12 cmgrey / green1/12
70522incl. sliding door 70560220 mm330 mmgrey / greenS1
70523incl. sliding door 70570300 mm400 mmgrey / greenM1
70524incl. sliding door 70580430 mm400 mmgrey / greenL1
Accessories
Ref. no.DescriptionColourSizeMaterialLengthWidthHeightØMOQPieces / unitPU
70551Pulleysgrey Plastic   3.5 cm1 pouch4 / pouch1
70552Replacement Cord for Chicken Doorwhite  1 m     1
70553Power Packblack Plastic5.5 cm3.5 cm6.5 cm   1/20
70554External Light Sensorblack Plastic1 m     1/50
70560Sliding Door incl. Guide Rails SAluminium 220 mm330 mm   1/10
70570Sliding Door incl. Guide Rails MAluminium 300 mm400 mm   1/10
70565External buttonblack / green Plastic7.5 cm3.5 cm2 cm   1/100
70558Extension Cable for Light Sensorblack Plastic4 m     1
70580Sliding Door incl. Guide Rails LAluminium 430 mm400 mm   1/10


Reliable protection: The stable is reliably protected against nocturnal intruders such as foxes and martens. In the event of resistance or overload, the motor switches off automatically – for maximum safety.

Control unit via app: Convenient operation via smartphone in the local Wi-Fi network – settings and manual opening or closing directly via the app. The user-friendly design enables quick installation and easy handling.

Intelligent light control: The integrated sensor detects the brightness of the day and automatically controls the door according to the set brightness values. A delayed reaction prevents false openings caused by lightning or short-term light pulses.

Flexible time control: The door can also be controlled according to fixed times. Light and time control can be flexibly combined.

LED status display: The integrated indicator light provides reliable information about the power supply, Wi-Fi and Bluetooth connection, and possible malfunctions. Control is mains-operated a solar battery kit is available separately for a self-sufficient power supply.

Items 70524 and 70580 are suitable for commercial animal farming in accordance with TierschNutztV (access opening min. 40 x 35 cm)

  • 1 x control unit
  • 1 x power pack
  • 1 x instruction manual
