Modular Calf Box

The modular calf box offers flexible housing solutions for individual and group housing and impresses with its quick assembly, easy cleaning and space-saving storage.

can be used flexibly as an individual pen or group pen
one box offers approx. 1.8 m2 of space (1.60 x 1.15 m)
up to three boxes can be combined to create a group bay
can be set up freestanding or against a wall
fast and simple assembly and removal in just a few simple steps
easy-to-clean, smooth plastic walls
space-saving stackable design includes door element
can be transported using the carrying handle or a pallet fork
front section with hinged door and fixed drinking area
social contact opening in the side walls
no need to drill holes in the floor for fastening

14626 Scope of delivery:

1 x Front Element, Door (14620)

2 x Side Wall (14621)

1 x Back Wall (14622)

4 x Locking Rod (14624)

14627 Scope of delivery:

1 x Front Element, Door (14620)

2 x Side Wall (14621)

4 x Locking Rod (14624)

2 x Wall Mounting Accessory (14625)

14628 Scope of delivery:

2 x Front Element, Door (14620)

3 x Side Wall (14621)

2 x Back Wall (14622)

2 x Stabilising Aid, Group Box (14623)

6 x Locking Rod (14624)

14629 Scope of delivery:

2 x Front Element, Door (14620)

3 x Side Wall (14621)

1 x Stabilising Aid, Group Box (14623)

6 x Locking Rod (14624)

3 x Wall Mounting Accessory (14625)

14630 Scope of delivery:

1 x Front Element, Door (14620)

1 x Side Wall (14621)

1 x Back Wall (14622)

2 x Stabilising Aid, Group Box (14623)

2 x Locking Rod (14624)

14631 Scope of delivery:

1 x Front Element, Door (14620)

1 x Side Wall (14621)

1 x Stabilising Aid, Group Box (14623)

2 x Locking Rod (14624)

1 x Wall Mounting Accessory (14625)

Local animal protection regulations must be observed.

Items

Ref. no.	Description	Material	PU
14626	Single Bay, Free Standing	galvanised metal / Plastic	1
14627	Single Bay, Wall-Standing	galvanised metal / Plastic	1
14628	Twin Bay, Free Standing	galvanised metal / Plastic	1
14629	Twin Bay, Wall-Standing	galvanised metal / Plastic	1
14630	Single-Bay Extension, Free Standing	galvanised metal / Plastic	1
14631	Single-Bay Extension, Wall-Standing	galvanised metal / Plastic	1

Accessories

Ref. no.	Description	Material	Length	Width	Height	PU
14620	Front element, door for modular calf box Front Element, Door	galvanised metal	125 cm	10 cm	114 cm	1
14621	Wall for modular calf box Side Wall	Plastic	167 cm	8 cm	112 cm	1
14622	Wall for modular calf box Rear Wall	Plastic	125 cm	8 cm	112 cm	1
14623	Assembly accessories for modular calf box Stabilisation Aid for Group Box	galvanised metal	40 cm	7.5 cm	2.5 cm	1
14624	Assembly accessories for modular calf box Locking Rod	galvanised metal	110 cm	1.5 cm	2.5 cm	1
14625	Assembly accessories for modular calf box Wall mounting accessory	galvanised metal	5.5 cm	4 cm	36 cm	1
14632	Roof mount for modular calf box Roof mount	galvanised metal	127 cm	7 cm	12.5 cm	1

Item. No.	Description	14626	14628	14629	14630	14631
1408	Mounting Bracket for Feeding	x	x	x	x	x
14621	Side Wall	x	x	x	x	x
14622	Rear Wall	x	x		x
14623	Stabilising Aid Group Box		x	x	x	x
14624	Locking Rod	x	x	x	x	x
14625	Wall mounting accessory			x		x
14620-1	Front elem. doors w/o access.	x	x	x	x	x
14620-2	Access. for front elem. doors	x	x	x	x	x
